Machine
Kawaguchi – K80
Product description:
Specification
Screw Diameter mm 36
Shot Volume with Ps g 128
Shot Size (Theoretical) cm3 142
Injection Pressure kg/cm2 1800 | 2000
Injection Rate cm3/sec 89(74) 81 (67)
Plasticizing Capacity kg/hr 38(32
Injection Stroke mm 140
Screw Speed rpm 40 ~ 225 (190
Screw Torque kg/m 59.2
Hopper Capacity l 30
Mold Clamping Force ton 80
Mold Opening Force ton 2.3
Max. Toggle Stroke mm 305
Min. Mold Height mm 180
Max. Mold Height mm 330
Clearance Between Tie Bars (H x V) mm 360 x310
Mold Platens (H x V) mm 520 x 470
Ejecting Force ton 2.2
Ejector Stroke mm 70
Max. Closing Speed mm/sec 478 (398)
Max. Opening Speed mm/sec 671 (559)
Barrel Heater kW 7.5 9
Pump Motor kW 15
Total Power Consumption kW 24
Pump Output l /min 49.2(40.9)
Hydraulic Oil Required l 240
Machine Dimensions (L x W x H) m4.18 x 1.05 x 1.81
Machine Weight ton 3.8
Shot Volume with Ps g 128
Shot Size (Theoretical) cm3 142
Injection Pressure kg/cm2 1800 | 2000
Injection Rate cm3/sec 89(74) 81 (67)
Plasticizing Capacity kg/hr 38(32
Injection Stroke mm 140
Screw Speed rpm 40 ~ 225 (190
Screw Torque kg/m 59.2
Hopper Capacity l 30
Mold Clamping Force ton 80
Mold Opening Force ton 2.3
Max. Toggle Stroke mm 305
Min. Mold Height mm 180
Max. Mold Height mm 330
Clearance Between Tie Bars (H x V) mm 360 x310
Mold Platens (H x V) mm 520 x 470
Ejecting Force ton 2.2
Ejector Stroke mm 70
Max. Closing Speed mm/sec 478 (398)
Max. Opening Speed mm/sec 671 (559)
Barrel Heater kW 7.5 9
Pump Motor kW 15
Total Power Consumption kW 24
Pump Output l /min 49.2(40.9)
Hydraulic Oil Required l 240
Machine Dimensions (L x W x H) m4.18 x 1.05 x 1.81
Machine Weight ton 3.8
Kawaguchi – KS-110-E
Product description:
Made In : Japan
Kawaguchi – KS-40-S
Product description:
Specification
• Clamping force: 40 ton
• Screw diameter: 27 mm
• Shot volume: 65 cm3
• Main: 18 Kw
• Motor: 11 Kw
• Heater: 5.2 Kw
• Space between tie bars (HxV): 280X240 mm
• Platen size (HxV): 430X400 mm
• Machine dimensions(LxWXH): 3400X1050X1800 mm
• Machine weight: 1,700 Kg
• Screw diameter: 27 mm
• Shot volume: 65 cm3
• Main: 18 Kw
• Motor: 11 Kw
• Heater: 5.2 Kw
• Space between tie bars (HxV): 280X240 mm
• Platen size (HxV): 430X400 mm
• Machine dimensions(LxWXH): 3400X1050X1800 mm
• Machine weight: 1,700 Kg
Kawaguchi (INJECTION MACHINE ) KS-40-S
Specification:
*Clamping Force :40 ton
*Screw Diameter :27 mm
*Shot volume :65 cm3
*Main :18 kW
*Motor :11 kW
*Heater :5.2 kW
*Space Between
tier bar (HxW):280×240 mm
*Platen Size :430×400 mm
*Machine Dimension:3400 x 1050 x1800 mm
*Machine Weight : 1,700 kg
KIA KIT 30B
CONTACT US :
| SALES DEPARTMENT | : | +6012 – 363 0948 / +012 – 3830738 |
| OFFICE | : | +603 – 6099 2938/2928 |
| FACSIMILE (FAX) | : | +603 – 6099 2968 |
| ELECTRONIC MAIL (E-MAIL) | : | multipro_mh@yahoo.com |
KIA KIT-30B
Product description:
A retrofited CNC Lathes machine
| pecification | Description |
|---|---|
| Maximum Swing | 18.9″ |
| Maximum Swing over Cross Slide | 6.69″ |
| Maximum Machining Diameter | 5.9″ |
| Maximum Machining Length | 5.9″ |
| Hole Thru Spindle | 1.8″ |
| Bar Capacity | 1.5″ |
| Spindle Drive | 7.5 HP |
| Spindle Speeds | 50-5000 RPM |
| Cross Travel: X-Axis | 9.8″ |
| Longitudinal Travel: Z-Axis | 15.7″ |
| X-Axis Rapid Traverse Rate | 984 IPM |
| Z-Axis Rapid Traverse Rate | 1181 IPM |
| Approximate Dimensions | 96″ LR x 56″ FB x 72″H |
| Approximate Weight | 6000 lbs |
KS-110S
Product description:
Specification
Injection Moulding Machine, 175 Ton
• Year: 1981
• Clamping force: 175 ton
• Screw diameter: 50 mm
• Shot volume : 373 cm3
• Main : 43 Kw
• Motor : 30 Kw
• Heater ; 12 Kw
• Space between tie bars (HxV) : 440×450 mm
• Platen size (HxV) : 680×690 mm
• Machine dimensions(LxWXH) : 5,500×1,200×2,000 mm
• Machine weight : 7,200 Kg
KS-175-S
Product description:
Specification
• Clamping force: 175 ton
• Screw diameter: 50 mm
• Shot volume: 572 cm3
• Main: 43 Kw
• Motor: 30 Kw
• Heater : 12 Kw
• Space between tie bars (HxV): 445×445 mm
• Platen size (HxV): 680×690 mm
• Machine dimensions(LxWXH): 5,900×1,150×1,820 mm
• Machine weight: 6,800 Kg
• Capacity 175 Ton
• Screw diameter: 50 mm
• Shot volume: 572 cm3
• Main: 43 Kw
• Motor: 30 Kw
• Heater : 12 Kw
• Space between tie bars (HxV): 445×445 mm
• Platen size (HxV): 680×690 mm
• Machine dimensions(LxWXH): 5,900×1,150×1,820 mm
• Machine weight: 6,800 Kg
• Capacity 175 Ton
LASER 800
Product description:
Max engrave area | 800mm x 800mm (31.2″ x 31.2″) |
Max engrave speed | 3300mm/s |
Min engrave speed | 2mm/s |
Max acceleration | Up to 50G |
Height | 2240mm (87.3″) |
Width | 1280mm (49.9″) without shuttle feed |
Depth | 1950mm (76″) |
Weight | 650kg |
Image formats | TIFF, JPEG, BMP |
Vector formats | DXF, AI, EPS, CDR, DST, HPGL |
Laser power | 50, 100, 200 or 400 Watts |
Options – Conveyor feed, shuttle bed feed (pictured) | |
Le Blond Makino – V001
Product description:
Specification
Table Working Surface 49.25″ x 23.5″
Table Load Capacity 4,645 lbs
Longitudinal Travel (X-Axis) 41.3″
Cross Travel (Y-Axis) 23.6″
Vertical Travel (Z-Axis) 21.6″
Spindle Nose to Table 7″ – 28.6″
Rapid Traverse Rate (X & Y-Axes) 787 IPM
Rapid Traverse Rate (Z-Axis) 200 IPM
Tool Storage Capacity 24
Spindle Horsepower 15 HP
Spindle Speeds Range 10-4000 RPM
Spindle Taper #40 BT
Electrics 460/3/60
Approximate Machine Dimensions 6’3″ x 8’2″
Approximate Machine Height Max 10’8″
Approximate Machine Weight 17,000 LBS
Table Load Capacity 4,645 lbs
Longitudinal Travel (X-Axis) 41.3″
Cross Travel (Y-Axis) 23.6″
Vertical Travel (Z-Axis) 21.6″
Spindle Nose to Table 7″ – 28.6″
Rapid Traverse Rate (X & Y-Axes) 787 IPM
Rapid Traverse Rate (Z-Axis) 200 IPM
Tool Storage Capacity 24
Spindle Horsepower 15 HP
Spindle Speeds Range 10-4000 RPM
Spindle Taper #40 BT
Electrics 460/3/60
Approximate Machine Dimensions 6’3″ x 8’2″
Approximate Machine Height Max 10’8″
Approximate Machine Weight 17,000 LBS
MAKINO RMC 55
Product description:
Specifications
| Overall Table Size: | 31.5″ x 12.6″ |
|---|---|
| X-Axis Travel: | 21.6″ |
| Y-Axis Travel: | 12.6″ |
| Z-Axis Travel: | 13.8″ |
| Spindle Speeds: | 45 – 4,500 RPM |
| Spindle Feeds: | 0 – 315 IPM |
| Feed Rate: | .04 – 197 IPM |
| Spindle Nose to Table Top: | 4″ – 17.75″ Maximum |
| Spindle Center to Column: | 2.95″ – 15.55″ |
| Spindle Taper: | ISO 40 |
| Spindle HP: | 5/7.5 |
| Rapid Traverse Rate (X,Y,Z-Axes): | 470, 470, 315 IPM |
| Table Load Capacity: | 550 Lbs |
