Machine
Awea – VP1050
Product description:
Specification
Table Working Surface 49.25″ x 23.5″
Table Load Capacity 4,645 lbs
Longitudinal Travel (X-Axis) 41.3″
Cross Travel (Y-Axis) 23.6″
Vertical Travel (Z-Axis) 21.6″
Spindle Nose to Table 7″ – 28.6″
Rapid Traverse Rate (X & Y-Axes) 787 IPM
Rapid Traverse Rate (Z-Axis) 200 IPM
Tool Storage Capacity 24
Spindle Horsepower 15 HP
Spindle Speeds Range 10-4000 RPM
Spindle Taper #40 BT
Electrics 460/3/60
Approximate Machine Dimensions 6’3″ x 8’2″
Approximate Machine Height Max 10’8″
Approximate Machine Weight 17,000 LBS
Table Load Capacity 4,645 lbs
Longitudinal Travel (X-Axis) 41.3″
Cross Travel (Y-Axis) 23.6″
Vertical Travel (Z-Axis) 21.6″
Spindle Nose to Table 7″ – 28.6″
Rapid Traverse Rate (X & Y-Axes) 787 IPM
Rapid Traverse Rate (Z-Axis) 200 IPM
Tool Storage Capacity 24
Spindle Horsepower 15 HP
Spindle Speeds Range 10-4000 RPM
Spindle Taper #40 BT
Electrics 460/3/60
Approximate Machine Dimensions 6’3″ x 8’2″
Approximate Machine Height Max 10’8″
Approximate Machine Weight 17,000 LBS
Band Saw – UE-712A
Product description:
Specification
Type Magnetic switch
Power 1HP motor
Blade Speed Step Pulley 22/33/45/65 MPM
Blade Size 19mm x 0.9mm x 2360mm
Cutting Capacity at 90° Round: 180mm
Rectangle (H x W): 180 x 280mm
Rectangle (H x W): 65 x 300mm
Cutting Capacity at 45° Round: 110mm
Rectangle (H x W) 180 x 110mm
Weight 130kg
Power 1HP motor
Blade Speed Step Pulley 22/33/45/65 MPM
Blade Size 19mm x 0.9mm x 2360mm
Cutting Capacity at 90° Round: 180mm
Rectangle (H x W): 180 x 280mm
Rectangle (H x W): 65 x 300mm
Cutting Capacity at 45° Round: 110mm
Rectangle (H x W) 180 x 110mm
Weight 130kg
Bridgeport Interact 1 Mk2 CNC Mill
Product description:
Control: Heidenhain TNC 2500
Table size 1066 x 317 mm
X-,Y,Z travels: 457, 305, 125 mm
Table can move manually 365mm up and down
Spindle nose 30 ISO Bristol Erickson
Spindle speeds 50 – 3750rpm
Feeds 1 – 5000mm/min
Rapid 5m/min
Chevalier – FSG-618
Product description:
Specification
Ball Table ways
Double “V” + Turcite-B on Z-Axis
Table Travel: 175 x 480mm (7″ x 19″)
Chuck Size: 150 x 450mm (6″ x18″)
Table Surface to Spindle Center: 450mm (18″)
Spindle Speed: 3,450rpm
Spindle Power: 2HP
Double “V” + Turcite-B on Z-Axis
Table Travel: 175 x 480mm (7″ x 19″)
Chuck Size: 150 x 450mm (6″ x18″)
Table Surface to Spindle Center: 450mm (18″)
Spindle Speed: 3,450rpm
Spindle Power: 2HP
CTX 200
Product description:
Specification
Control: DINPlus
X-travel: 160 mm
Z-travel: 350 mm
Spindle bore: 56 mm
Spindle head: 120 H 5 mm
Freight basis: EX WORKS
Spindle drive: 14 kW
Turning length: 400 mm
Type of control: CNC
Turning diameter: 210 mm
Bar material dia.: 42 mm
12-position turret: VDI 30th
Turning speed range: 25 – 5000 rpm
Cnc heidenhain dinplus: YES
Great pass over the bed: 440 mm
Total power requirement: 22 kW
No. of tools in turret 1: 12 x VDI 30
Weight of the machine approx.: 3 t
Dimensions of the machine approx.: 2.8 x 1.7 x 1.8 m
Spindle diameter in front bearing: 85 mm
CTX 200 GILDEMEISTER
